Examples
Real parts, circuits and flights, each run with Wobbl, and every number here comes from that run’s own output.
StrengthCast motor mountDoes a cast motor mount meet a safety factor of 2 under a 2 kN belt pull?MARGINAL 124 MPa
StrengthShelf bracketDoes a printed PLA bracket hold an 8 kg shelf, and what fixes it?FAILS 52.3 MPa
StrengthMotor mountDo the ribs on a printed NEMA 17 mount earn their keep?HOLDS 11 MPa
StrengthEnclosureDoes a polycarbonate shell survive a thumb press, and how far does it dent?HOLDS 8.77 MPa
StrengthDrone armIs a printed PA12 drone arm strong enough at full throttle?HOLDS 9.46 MPa
HeatHeat sinkDoes a 15 W chip stay under 85 C without a fan?OK 70.3 C
HeatBattery packWhen does a pack in a sealed box pass 60 C?HOT 74.5 C- CircuitsCircuitsWill this LED fry, what is the ripple and how hot does the MOSFET get?FAILS 36.9 mA
36.9 mA
LED current
MotionFalling rockHow fast does a rock hit the ground after a 300 m fall?OK 8.72 s MotionRocket launchWill an L class rocket fly straight, reach 11,000 ft and land softly in a 10 mph wind?OK 3439 m
